K-3JREH
Model
K-3JREH
Working weight
1,090 lb
495 kg
Recommended Carrier Weight Range (3rd member)
9,000 - 15,500 lb
4 - 7 metric tons
K-3JREH demolition shears are suited for skid steers, backhoes, and mini excavators within the recommended carrier weight ranges listed in the specifications below. Or visit the Attachment Wizard to see which NPK demolition shear (or other attachment) is best suited for your carrier!
Visit and subscribe to NPK's YouTube channel for videos of demolition shears in action!
Visit NPK's photo website for searchable demolition shear photo galleries!
Visit the Demolition Shear Publications page for sales brochures and instruction manuals.
If you would like a hard copy of the instruction manual, please contact the Sales department at 440-232-7900 or by email at sales@npkce.com.
Additional Images:
| Recommended Carrier Weight Range (2nd member) | 4,500 - 9,000 lb | 2 - 4 metric tons |
| Recommended Carrier Weight Range (Skidsteer) | 5,000 lb | 2,270 kg |
| Maximum Jaw Opening | 14.0 in | 355 mm |
| Maximum Jaw Depth | 13.9 in | 352 mm |
| Oil Flow | 8 - 16 gpm | 30 - 60 lpm |
| Operating Pressure | 2,610 psi | 180 bar |
| Maximum Cut/Pierce Force | 164,110 lbf | 730 kN |
| Cutting Capacity Round Bar (Mild Steel, Single Pass) | ||
| Cutting Capacity Flat Plate (Mild Steel, Single Pass) | ||
| Cycle Time (Sec) | 1.2 close / 0.6 open |
